DONGHAO · Industrial & Port Tires
I-3
Forklift · 29x12.50-15NHS – 15.5/80-24IMP
Solid construction. 3 sizes listed, 29x12.50-15NHS to 15.5/80-24IMP.
Specifications by size
| Size | Construction | PR / Star | Tube | Recommended rim | Overall diameter (mm) | Section width (mm) | Tread depth (mm) | Max load (kg) | Inflation (kPa) | Enquire |
|---|---|---|---|---|---|---|---|---|---|---|
| 29x12.50-15NHS | Solid | 8PR | Tubeless | 10 | 742 | 310 | 20 | 1,080 | 310 | Enquire 29x12.50-15NHS |
| 31x15.50-15NHS | Solid | 12PR | Tubeless | 13LB | 792 | 391 | 21 | 1,680 | 520 | Enquire 31x15.50-15NHS |
| 15.5/80-24IMP | Bias | 16PR | Tubeless | W13 | 1,262 | 384 | 39 | 4,875 | 400 | Enquire 15.5/80-24IMP |
Specifications are indicative. Confirm the final specification, availability and terms on the quotation.
Specification source: manufacturer published data for this pattern
